| AMBIENT | 40 °C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 11 IN |
| CATALOG NUM | C246 |
| CE | No |
| CONNECTION DRAWING NO | 17050317.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 6.5/13.0 A |
| FRAME | Y56Y |
| FRAME LENGTH | 5.82 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 16 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C246 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Cap |
| MOUNTING | Cushion Ring |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Clockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.25 |
| SHAFT | 0.625 IN X 1.18 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.18 IN |
| SHAFT TYPE | Keyed |
| SKU | CM-C246 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674015563 |
| VOLTAGE | 115/230 V |
| WEIGHT STATIC | 33 LB |
| WIDTH | 8 IN |
