| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 11.62 IN |
| CATALOG NUMBER | C233 |
| CONNECTION DRAWING NO | 17050317.PCX |
| DUTY | Continuous |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 10.4/5.2 A |
| FRAME | L56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 16 IN |
| MANUFACTURE MODEL NUMBER | C233 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Cap |
| MOUNTING | Cushion Ring |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 3/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 3/4HP, 115/230, OD, 1725RPM |
| PRODUCT SKU | CM-C233 |
| ROTATION | Reversible Clockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.3 |
| SHAFT | 0.625 IN X 1.37 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 1.37 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115/230 V |
| WIDTH | 8 IN |
