| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 55 IN |
| CATALOG NUM | C036 |
| CE | No |
| CONNECTION DRAWING NO | 18565718.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 5 A |
| FRAME | Y56Z |
| FRAME LENGTH | 6.13 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.75 IN |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 59 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C036 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Cushion Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | C036 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Counterclockwise |
| RPM | 850(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.749 IN X 22.97 IN |
| SHAFT DIAMETER IN IN | 0.749 IN |
| SHAFT EXTENSION | 22.97 IN |
| SHAFT TYPE | Special Extension |
| SKU | CM-C036 |
| SPEED | 850 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674015044 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 53 LB |
| WIDTH | 9.06 IN |
