| AMBIENT | 40 °C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 24.7 IN |
| CATALOG NUM | C024 |
| CE | No |
| CONNECTION DRAWING NO | 18304020.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 6 A |
| FRAME | K56Y |
| FRAME LENGTH | 5.5 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 3/4 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 28 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | C024 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Cushion Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| PART ID | C024 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.665 IN X 7.5 IN |
| SHAFT DIAMETER IN IN | 0.665 IN |
| SHAFT EXTENSION | 7.5 IN |
| SHAFT TYPE | Flat |
| SKU | CM-C024 |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674014962 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 37 LB |
| WIDTH | 12 IN |
