| BEARING | Ball |
| BRAND | Century |
| CATALOG NUMBER | B2235 |
| CURRENT2 | 12.0/3.0 A |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FRAME | R56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 11 IN |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 16 IN |
| MANUFACTURE MODEL NUMBER | B2235 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR ORIENTATION | Horizontal |
| MOTOR TYPE | PERMANENT SPLIT CAPACITOR / CAPACITOR START / CAPACITOR RUN |
| MOUNTING | Thru Bolt |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 2 |
| OUTPUT | 4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 4,3600(2),230,56Y,ODP,PSC,WATERWAY REPLACEMENT |
| PRODUCT SKU | CM-B2235 |
| ROTATION | Counterclockwise Pump End |
| RPM | 3450/1725(2) |
| SERVICE FACTOR | 1 |
| SHAFT DIAMETER (IN IN.) | 0.5 IN |
| SHAFT EXTENSION | 2.37 IN |
| SHAFT TYPE | 3/8 Threaded |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230 V |
| WEIGHT | 38 LB |
| WIDTH | 9.5 IN |
