| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.78 IN |
| CATALOG NUM | YA2020 |
| CATALOG NUM STATIC | Ya2020 |
| CE | No |
| CONNECTION DRAWING NO | 621417-011A |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 4.2 A |
| FRAME | 48YZ |
| FRAME LENGTH | 4.94 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 48Yz |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| HORSE POWER | 1/4 HP |
| HORSE POWER STATIC | 4-Jan |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 11 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | YA2020 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Yoke |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | YA2020 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| RPM STATIC | 1800 |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 1.88 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 1.88 IN |
| SHAFT TYPE | Flat |
| SKU | YA2020 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | No |
| UOM | Each |
| UPC NUMBER | 786674033994 |
| VOLTAGE | 115 V |
| VOLTAGE STATIC | 115 |
| WEIGHT STATIC | 14 LB |
| WIDTH | 8 IN |
