| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 9.83 IN |
| CATALOG NUM | SVB2074BV1 |
| CE | No |
| CONNECTION DRAWING NO | 630415-001 |
| COUNTRY OF ORIGIN | China |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 9.8/6.4 A |
| FRAME | 56Z |
| FRAME LENGTH | 5.20 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.81 IN |
| HORSE POWER | 3/4-1/3 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 10.81 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | SVB2074BV1 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | SVB2074BV1 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725/1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 1.88 IN |
| SHAFT DIAMETER IN IN | 0.625 IN |
| SHAFT EXTENSION | 1.88 IN |
| SHAFT TYPE | Keyed |
| SKU | SVB2074BV1 |
| SPEED | 1725/1140 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674032010 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 23 LB |
| WIDTH | 7.81 IN |
