| AMBIENT | 25°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 4.22 IN |
| CATALOG NUM | SS-613 |
| CATALOG NUM STATIC | Ss-613 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 0.51 A |
| FRAME | C-Frame |
| FRAME STATIC | C-Frame |
| FREQUENCY | 60 HZ |
| HEIGHT | 3 IN |
| HORSE POWER | 1/2 STACK HP |
| HORSE POWER STATIC | 2-Jan |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 4.5 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | SS-613 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Bracket |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| PART ID | SS-613 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Shaft End |
| RPM | 3000(1) |
| RPM STATIC | 3600 |
| SERVICE FACTOR | 1 |
| SHAFT | 0.217 X 2.51 IN |
| SHAFT DIAMETER IN IN | 0.217 IN |
| SHAFT EXTENSION | 2.51 IN |
| SHAFT TYPE | Flat & Groove |
| SKU | SS-613 |
| SPEED | 3000 |
| STARTING TYPE | Induction Run |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | No Protection |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674053657 |
| VOLTAGE | 120 V |
| VOLTAGE STATIC | 120 |
| WEIGHT STATIC | 1 LB |
| WIDTH | 2.88 IN |
