| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.97 IN |
| CATALOG NUM | SGF2054AV2 |
| CE | No |
| CONNECTION DRAWING NO | 620005-038A |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 8.8-4 A |
| FRAME | 56Z |
| FRAME LENGTH | 5.19 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/2-1/6 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | SGF2054AV2 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4/6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | SGF2054AV2 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725/1140(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.500 IN X 1.42 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 1.42 IN |
| SHAFT TYPE | Flat |
| SKU | SGF2054AV2 |
| SPEED | 1725/1140 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| THRU BOLTS EXTENSION | Yes |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674030931 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 21 LB |
| WIDTH | 10 IN |
