| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 11.07 IN |
| CATALOG NUM | SGF2034V3 |
| CE | No |
| CONNECTION DRAWING NO | 17050311.PCX |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | DRIP PROOF |
| FL AMPS | 5.2/3 A |
| FRAME | J56Z |
| FRAME LENGTH | 5.13 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/3-1/15 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 16 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | SGF2034V3 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Cushion Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4/8 |
| NUMBER OF SPEEDS | 2-2-VT |
| OVERLOAD | Automatic |
| PART ID | SGF2034V3 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725/850(2-2-VT) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 1.94 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 1.94 IN |
| SHAFT TYPE | Keyed |
| SKU | SGF2034V3 |
| SPEED | 1725/850 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674030917 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 44 LB |
| WIDTH | 8 IN |
