| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.17 IN |
| CATALOG NUM | RF4401 |
| CE | No |
| CONNECTION DRAWING NO | 7571A67F01 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 4/2 A |
| FRAME | 42Y |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 50/60 HZ |
| HEIGHT | 5.81 IN |
| HORSE POWER | 1/10 HP |
| INSULATION CLASS | A |
| LEAD TIME | 18 |
| LENGTH | 8.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | RF4401 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | RF4401 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1550/1300(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.375 IN X 2.25 IN |
| SHAFT DIAMETER IN IN | 0.375 IN |
| SHAFT EXTENSION | 2.25 IN |
| SHAFT TYPE | Flat |
| SKU | RF4401 |
| SPEED | 1550/1300 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674030603 |
| VOLTAGE | 115/208-230 V |
| WEIGHT STATIC | 10 LB |
| WIDTH | 5.81 IN |
