| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.12 IN |
| CATALOG NUMBER | OYK1056V1 |
| CONNECTION DRAWING NO | 614131-003 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 2.2-2.5 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 11 IN |
| MANUFACTURE MODEL NUMBER | OYK1056V1 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Down |
| OUTPUT | 1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2,1090,208-230,48,TE,PSC,YORK OEM |
| PRODUCT SKU | OYK1056V1 |
| ROTATION | Clockwise Lead End |
| RPM | 1090(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4 IN |
| SHAFT TYPE | Double Flat |
| SPEED | 1090 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 7.5 IN |
