| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.86 IN |
| CATALOG NUM | OYK1056S |
| CE | No |
| CONNECTION DRAWING NO | 614131-003 |
| CSA | Yes |
| DUTY | Air Over |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 9.8 A |
| FRAME | 48Y |
| FRAME LENGTH | 4.88 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.81 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | OYK1056S |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | OYK1056S |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1110(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.5 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 4.5 IN |
| SHAFT TYPE | Flat |
| SKU | OYK1056S |
| SPEED | 1110 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674028730 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 18 LB |
| WIDTH | 8.31 IN |
