| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 6.15 IN |
| CATALOG NUMBER | OTC6001 |
| CONNECTION DRAWING NO | 261B865F01 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 1.3 A |
| FRAME | 42Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 5.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 8.87 IN |
| MANUFACTURE MODEL NUMBER | OTC6001 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Shp |
| MOUNTING | Special |
| NOMINAL EFFICIENCY | 26 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/15 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/15,230,1550/1300,OPEN,60/50,SHADE POLE |
| PRODUCT SKU | OTC6001 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1500/1300(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.312 IN X 2.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.312 IN |
| SHAFT EXTENSION | 2.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1500/1300 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230 V |
| WIDTH | 5.81 IN |
