| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 13 IN |
| CATALOG NUMBER | OSR1026 |
| CONNECTION DRAWING NO | 614131-015 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 17.12 IN |
| MANUFACTURE MODEL NUMBER | OSR1026 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | A.O. SMITH,OSR1026 |
| PRODUCT SKU | OSR1026 |
| ROTATION | Clockwise Lead End |
| RPM | 1025(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.5 X .5 X 4.2 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4.5X.5X4.2 IN |
| SHAFT TYPE | Flat |
| SPEED | 1025 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 7.31 IN |
