| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 8.15 IN |
| CATALOG NUM | ORM1058 |
| CE | No |
| CONNECTION DRAWING NO | 614131-205 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 3.4 A |
| FRAME | 48Y |
| FRAME LENGTH | 4.25 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 13.18 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | ORM1058 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | ORM1058 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 825(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3.3 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 3.3 IN |
| SHAFT TYPE | Flat |
| SKU | ORM1058 |
| SPEED | 825 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674028211 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 15 LB |
| WIDTH | 7.25 IN |
