| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.78 IN |
| CATALOG NUMBER | ORM1028 |
| CONNECTION DRAWING NO | 614131-070 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| INSULATION CLASS | B |
| LENGTH | 13.18 IN |
| MANUFACTURE MODEL NUMBER | ORM1028 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Any |
| OUTPUT | 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/4,208-230,825(2),48,RHEEM RUDD,CCWLE |
| PRODUCT SKU | ORM1028 |
| ROTATION | Counterclockwise Lead End |
| RPM | 825(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3.4 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 3.4 IN |
| SHAFT TYPE | Flat |
| SPEED | 825 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 7.25 IN |
