| AMBIENT | 50°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 6.75 IN |
| CATALOG NUM | OPV747 |
| CE | No |
| CSA | Yes |
| DUTY | Air Over |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 2.5/2.1/1.6 A |
| FRAME | 42Y |
| FRAME LENGTH | 3.67 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/7, 1/11, 1/25 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 11 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | OPV747 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | OPV747 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1550/1300/1050(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 2.50 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 2.50 IN |
| SHAFT TYPE | Flat |
| SKU | OPV747 |
| SPEED | 1550/1300/1050 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | OPV747A |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674053244 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 10 LB |
| WIDTH | 11 IN |
