| BEARING | 203 Ball |
| BRAND | Century |
| C DIMENSION | 10.86 IN |
| CATALOG NUMBER | OLE1106 |
| CONNECTION DRAWING NO | 614131-036 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 5 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 15 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 10.5 IN |
| MANUFACTURE MODEL NUMBER | OLE1106 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NOMINAL EFFICIENCY | 67 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OUTPUT | 1 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1,1075,230,48,AIR-OVER,PSC,LENNOX REPL |
| PRODUCT SKU | OLE1106 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 5 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230 V |
| WIDTH | 9 IN |
