| AMBIENT | 40°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 10.50 IN |
| CATALOG NUM | OKT3035 |
| CE | No |
| CONNECTION DRAWING NO | 614131-336 |
| CSA | Yes |
| DUTY | Air Over |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 6.3/2.8-3.15 A |
| FRAME | 48 |
| FRAME LENGTH | 5.75 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 50/60 HZ |
| HEIGHT | 10 IN |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | OKT3035 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | OKT3035 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Opposite Shaft End |
| RPM | 1075/900(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3.5 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 3.5 IN |
| SHAFT TYPE | Flat |
| SKU | OKT3035 |
| SPEED | 1075/900 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674027764 |
| VOLTAGE | 115/208-230 V |
| WEIGHT STATIC | 15 LB |
| WIDTH | 7 IN |
