| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.87 IN |
| CATALOG NUMBER | OFE5001 |
| CONNECTION DRAWING NO | 621668 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED |
| FL AMPS | 1.5 A |
| FRAME | 42Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 5.81 IN |
| INSULATION CLASS | B |
| LENGTH | 10.87 IN |
| MANUFACTURE MODEL NUMBER | OFE5001 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/5 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/5,1350,208-230,CCWLE,FEDDERS OEM |
| PRODUCT SKU | OFE5001 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1350/1000(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3.8 X .5 X 2.8 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 3.8X.5X2.8 IN |
| SHAFT TYPE | Flat |
| SPEED | 1350/1000 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230/208 V |
| WIDTH | 5.81 IN |
