| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 8.11 IN |
| CATALOG NUMBER | OFE1016 |
| CONNECTION DRAWING NO | 614131-230 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 1.3 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 11 IN |
| MANUFACTURE MODEL NUMBER | OFE1016 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OUTPUT | 1/5 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | A.O. SMITH,OFE1016 |
| PRODUCT SKU | OFE1016 |
| ROTATION | Clockwise Lead End |
| RPM | 1080(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.3 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4.3 IN |
| SHAFT TYPE | Flat |
| SPEED | 1080 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230 V |
| WIDTH | 7.5 IN |
