| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 10 IN |
| CATALOG NUMBER | OEK4509 |
| CONNECTION DRAWING NO | 7555A73F01 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 2.4 A |
| FRAME | 42Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 5.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 10.87 IN |
| MANUFACTURE MODEL NUMBER | OEK4509 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/3 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | A.O. SMITH,OEK4509 |
| PRODUCT SKU | OEK4509 |
| ROTATION | Clockwise Lead End |
| RPM | 1400/1200(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 5.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 5.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1400/1200 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | No |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 5.81 IN |
