| AMBIENT | 60°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 12.60 IN |
| CATALOG NUM | OCA3076H |
| CATALOG NUM STATIC | Oca3076H |
| CE | No |
| CONNECTION DRAWING NO | 614131-147 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 1.9 A |
| FRAME | 48Y |
| FRAME LENGTH | 8.13 IN |
| FRAME MATERIAL | Rolled Steel |
| FRAME STATIC | 48 |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| HORSE POWER | 3/4 HP |
| HORSE POWER STATIC | 4-Mar |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 15.18 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | OCA3076H |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | 3Ph |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 3 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Down |
| OVERLOAD | Automatic |
| PART ID | OCA3076H |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1140(1) |
| RPM STATIC | 1200 |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 3 IN |
| SHAFT TYPE | Double Flat |
| SKU | OCA3076H |
| SPEED | 1140 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674027283 |
| VOLTAGE | 460 V |
| VOLTAGE STATIC | 460 |
| WEIGHT STATIC | 27 LB |
| WIDTH | 7.31 IN |
