| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 9.74 IN |
| CATALOG NUMBER | OCA1056 |
| CONNECTION DRAWING NO | 614131-194 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 4.6/2.3 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.1 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 10.2 IN |
| MANUFACTURE MODEL NUMBER | OCA1056 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OUTPUT | 1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2HP,1050,48,CND.FAN,CARRIER |
| PRODUCT SKU | OCA1056 |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 1.6 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 1.6 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 200-230/460 V |
| WIDTH | 12.2 IN |
