| AMBIENT | 60°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.82 IN |
| CATALOG NUM | OCA10206A |
| CE | No |
| CONNECTION DRAWING NO | 614131-052 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 1.3 A |
| FRAME | 48Y |
| FRAME LENGTH | 3.13 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| HORSE POWER | 1/5 HP |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 11 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | OCA10206A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Lug |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | OCA10206A |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1050(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.2 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 4.2 IN |
| SHAFT TYPE | Flat |
| SKU | OCA10206A |
| SPEED | 1050 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674027207 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 11 LB |
| WIDTH | 8 IN |
