| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 10.36 IN |
| CATALOG NUMBER | OAN747 |
| CONNECTION DRAWING NO | 614131-004 |
| DUTY | Air Over |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 12.87 IN |
| MANUFACTURE MODEL NUMBER | OAN747 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OUTPUT | 3/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 3/4,1200,460,48Y,TEAO,PSC,OEM-AAON |
| PRODUCT SKU | OAN747 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 1.875 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 1.875 IN |
| SHAFT TYPE | Double Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 460 V |
| WIDTH | 9.81 IN |
