| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 13.37 IN |
| CATALOG NUMBER | OAM10088 |
| CONNECTION DRAWING NO | 614131-318 |
| DUTY | Air Over |
| ENCLOSURE | TOTALLY ENCLOSED AIR OVER |
| FL AMPS | 0.5-0.6 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 5.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 8.87 IN |
| MANUFACTURE MODEL NUMBER | OAM10088 |
| MANUFACTURER | Regal Beloit Epc |
| MOUNTING | Extended Studs |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/12 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/12,825,208-230,48Y,CWLE |
| PRODUCT SKU | OAM10088 |
| ROTATION | Clockwise Lead End |
| RPM | 825(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 2.3 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 2.3 IN |
| SHAFT TYPE | Flat |
| SPEED | 825 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 5.81 IN |
