| AMBIENT | 50°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 8.29 IN |
| CATALOG NUM | HW2024B1L |
| CE | No |
| CONNECTION DRAWING NO | 2511148-001 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3.5 A |
| FRAME | 48Z |
| FRAME LENGTH | 4.34 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| HORSE POWER | 1/4 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 11 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | HW2024B1L |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | Resilient Base |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Automatic |
| PART ID | HW2024B1L |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible Counterclockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.75 |
| SHAFT | 0.500 IN X 0.83 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 0.83 IN |
| SHAFT TYPE | Spot Drill |
| SKU | HW2024B1L |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674025326 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 16 LB |
| WIDTH | 8 IN |
