| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 10.18 IN |
| CATALOG NUMBER | HW2014V1L |
| CONNECTION DRAWING NO | 2511452-001 |
| DUTY | Continuous |
| ENCLOSURE | OPEN DRIP PROOF |
| FL AMPS | 3 A |
| FRAME | 48Z |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.5 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 14 IN |
| MANUFACTURE MODEL NUMBER | HW2014V1L |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Split Ph |
| MOUNTING | Cushion Ring |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 1/6 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/6,1800,115,48Z,ODP,SPLIT |
| PRODUCT SKU | HW2014V1L |
| ROTATION | Reversible Clockwise |
| RPM | 1725(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT | 0.500 IN X 8.73 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 8.73 IN |
| SHAFT TYPE | Flat |
| SPEED | 1725 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 8 IN |
