| BEARING | Ball |
| BRAND | Century |
| CATALOG NUMBER | HSQ1202 |
| CURRENT2 | 12.0-11.0 A |
| DUTY | Continuous |
| EFFICIENCY | E$ |
| ENCLOSURE | OPEN DRIP PROOF |
| FRAME | Y56Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 11 IN |
| INSULATION CLASS | F |
| LEAD TIME | 17 |
| LENGTH | 16 IN |
| MANUFACTURE MODEL NUMBER | HSQ1202 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR ORIENTATION | Horizontal |
| MOTOR TYPE | CAPACITOR START / CAPACITOR RUN |
| MOUNTING | Round |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 1 |
| OUTPUT | 2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 2,3600,208-230,56Y,ODP,CSCR,TRISTAR REPL |
| PRODUCT SKU | AO-HSQ1202 |
| ROTATION | Counterclockwise Pump End |
| RPM | 3450(1) |
| SERVICE FACTOR | 1.35 |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 0.91 IN |
| SHAFT TYPE | 1/2 Threaded |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WEIGHT | 38 LB |
| WIDTH | 9.50 |
