| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 9.74 IN |
| CATALOG NUMBER | FSP4016S |
| CONNECTION DRAWING NO | 614131-231 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 3.2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| INSULATION CLASS | A |
| LEAD TIME | 18 |
| LENGTH | 13.18 IN |
| MANUFACTURE MODEL NUMBER | FSP4016S |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/5 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/5HP, 1050/1, PSC, 48,CCWLE |
| PRODUCT SKU | FSP4016S |
| ROTATION | Counterclockwise Lead End |
| RPM | 1050(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.8 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4.8 IN |
| SHAFT TYPE | Flat |
| SPEED | 1050 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 7.25 IN |
