| AMBIENT | 60°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 11.55 IN |
| CATALOG NUM | FS1036S |
| CE | No |
| CONNECTION DRAWING NO | 614131-115 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 3 A |
| FRAME | 48Y |
| FRAME LENGTH | 4 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| HORSE POWER | 1/3 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 14.18 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | FS1036S |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OVERLOAD | Automatic |
| PART ID | FS1036S |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 6.4 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 6.4 IN |
| SHAFT TYPE | Double Flat |
| SKU | FS1036S |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674021281 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 14 LB |
| WIDTH | 6.5 IN |
