| AMBIENT | 50°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 10.86 IN |
| CATALOG NUM | FML1056 |
| CE | No |
| CONNECTION DRAWING NO | 614131-111 |
| COUNTRY OF ORIGIN | India |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 8.5 A |
| FRAME | 48Y |
| FRAME LENGTH | 4.25 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 12.81 IN |
| HORSE POWER | 1/2 HP |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 12.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | FML1056 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Flexible Arms |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | FML1056 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 6 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 6 IN |
| SHAFT TYPE | Flat |
| SKU | FML1056 |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674021175 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 16 LB |
| WIDTH | 12.81 IN |
