| AMBIENT | 40°C |
| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 8.86 IN |
| CATALOG NUM | FD6002A |
| CE | No |
| CONNECTION DRAWING NO | 614131-265 |
| COUNTRY OF ORIGIN | India |
| CSA | Yes |
| DUTY | Air Over |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 2.1 A |
| FRAME | 48 |
| FRAME LENGTH | 4.75 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| HORSE POWER | 1/3-1/8 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 13.78 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | FD6002A |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 8 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | FD6002A |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 825(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3.5 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 3.5 IN |
| SHAFT TYPE | Flat |
| SKU | FD6002A |
| SPEED | 825 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| THRU BOLTS EXTENSION | Yes |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674065889 |
| VOLTAGE | 208-230 V |
| WEIGHT STATIC | 14 LB |
| WIDTH | 6.41 IN |
