| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 15.44 IN |
| CATALOG NUMBER | FC3106F |
| CONNECTION DRAWING NO | 614131-045 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 5.6/2.8 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.52 IN |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 17.95 IN |
| MANUFACTURE MODEL NUMBER | FC3106F |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | 3Ph |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OUTPUT | 1 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1HP, 1140, 200-230/460 |
| PRODUCT SKU | FC3106F |
| ROTATION | Reversible |
| RPM | 1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.625 IN X 4.07 IN |
| SHAFT DIAMETER (IN IN.) | 0.625 IN |
| SHAFT EXTENSION | 4.07 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1140 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 200-230/460 V |
| WIDTH | 10.03 IN |
