| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 12.68 IN |
| CATALOG NUMBER | FC3056F |
| CONNECTION DRAWING NO | 614131-045 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 3/1.5 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 15 IN |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 10.5 IN |
| MANUFACTURE MODEL NUMBER | FC3056F |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | 3Ph |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OUTPUT | 1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2,1140,200-230/460,48,OPEN AIR-OVER,3PH,E$ |
| PRODUCT SKU | FC3056F |
| ROTATION | Reversible |
| RPM | 1140(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3.85 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 3.85 IN |
| SHAFT TYPE | Flat |
| SPEED | 1140 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 200-230/460 V |
| WIDTH | 9 IN |
