| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 15.98 IN |
| CATALOG NUMBER | FC1156F |
| CONNECTION DRAWING NO | 614131-060 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 7/3.5 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 18 IN |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 10.5 IN |
| MANUFACTURE MODEL NUMBER | FC1156F |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OUTPUT | 1-1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1.5,1075,200-230/460,48,OPEN AIR-OVER,PSC,E$,70C |
| PRODUCT SKU | FC1156F |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.600 IN X 4.1 IN |
| SHAFT DIAMETER (IN IN.) | 0.600 IN |
| SHAFT EXTENSION | 4.1 IN |
| SHAFT TYPE | Keyed |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 200-230/460 V |
| WIDTH | 9 IN |
