| AMBIENT | 70°C |
| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 12.92 IN |
| CATALOG NUM | FC1066AF |
| CE | No |
| CONNECTION DRAWING NO | 614131-060 |
| CSA | Yes |
| DUTY | Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 4/2 A |
| FRAME | 48Y |
| FRAME LENGTH | 6.38 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 15 IN |
| HORSE POWER | 3/5 HP |
| INSULATION CLASS | F |
| LEAD TIME | 21 |
| LENGTH | 10.5 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | FC1066AF |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Vertical Shaft Up |
| OVERLOAD | Automatic |
| PART ID | FC1066AF |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1075(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.600 IN X 3.6 IN |
| SHAFT DIAMETER IN IN | 0.600 IN |
| SHAFT EXTENSION | 3.6 IN |
| SHAFT TYPE | Keyed |
| SKU | FC1066AF |
| SPEED | 1075 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674020345 |
| VOLTAGE | 200-230/460 V |
| WEIGHT STATIC | 19 LB |
| WIDTH | 9 IN |
