| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.41 IN |
| CATALOG NUM | EL2005 |
| CE | No |
| CONNECTION DRAWING NO | 631511-001B |
| COUNTRY OF ORIGIN | Mexico |
| CSA | No |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | TOTALLY ENCLOSED |
| FL AMPS | 2.12 A |
| FRAME | 48N |
| FRAME LENGTH | 3.44 IN |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| HORSE POWER | 1/8 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 11 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | EL2005 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Split Ph |
| MOUNTING | D-Flange / Round Body |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 1 |
| OVERLOAD | Manual |
| PART ID | EL2005 |
| PRODUCT GROUP | 3050 |
| ROTATION | Reversible |
| RPM | 1725(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 1.94 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 1.94 IN |
| SHAFT TYPE | Flat |
| SKU | EL2005 |
| SPEED | 1725 |
| STARTING TYPE | Across The Line |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674019400 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 10 LB |
| WIDTH | 8 IN |
