| BEARING | Ball |
| BRAND | Century |
| C DIMENSION | 19.11 IN |
| CATALOG NUMBER | DSB1024 |
| CONNECTION DRAWING NO | 614131-180 |
| DUTY | Continuous Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 2.4 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 23 IN |
| MANUFACTURE MODEL NUMBER | DSB1024 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/4 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/4,1625(2),115,48,AIR-OVER,PSC |
| PRODUCT SKU | DSB1024 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1625(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 7.5 X .5 X 7.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 7.5X.5X7.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1625 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 10 IN |
