| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 18.86 IN |
| CATALOG NUMBER | DSB1016H |
| CONNECTION DRAWING NO | 614131-106 |
| DUTY | Continuous Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 1.2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 23 IN |
| MANUFACTURE MODEL NUMBER | DSB1016H |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/6 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/6,1075(3),230,48,AIR-OVER,PSC |
| PRODUCT SKU | DSB1016H |
| ROTATION | Counterclockwise Lead End |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 7.5 X .5 X 7.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 7.5X.5X7.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 230 V |
| WIDTH | 10 IN |
