| AMBIENT | 40°C |
| BEARING | Sleeve |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| C DIMENSION | 20.92 IN |
| CATALOG NUM | DCL4423 |
| CE | No |
| CONNECTION DRAWING NO | 618126 |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 4 A |
| FRAME | 42Y |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| HORSE POWER | 1/6, 1/10, 1/12, 1/15 HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 22.87 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | DCL4423 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Resilient Rings |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 4 |
| ORIENTATION | Horizontal |
| OVERLOAD | Automatic |
| PART ID | DCL4423 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1550(4) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 8.5 X .5 X 8.5 IN |
| SHAFT DIAMETER IN IN | 0.500 IN |
| SHAFT EXTENSION | 8.5X.5X8.5 IN |
| SHAFT TYPE | Flat |
| SKU | DCL4423 |
| SPEED | 1550 |
| STARTING TYPE | Across The Line |
| STATUS | Active |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674018496 |
| VOLTAGE | 115 V |
| WEIGHT STATIC | 12 LB |
| WIDTH | 6.81 IN |
