| BEARING | Sleeve |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| C DIMENSION | 23.5 IN |
| CATALOG NUMBER | DB6504 |
| CONNECTION DRAWING NO | 7552A86F01 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 1.4 A |
| FRAME | 42Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 8.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 25.87 IN |
| MANUFACTURE MODEL NUMBER | DB6504 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Base |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/6 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/6,1075(3),208-230,42,AIR-OVER,PSC |
| PRODUCT SKU | DB6504 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1075(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 9.8 X .5 X 9.8 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 9.8X.5X9.8 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 8.81 IN |
