| BEARING | Sleeve |
| BLOWER TYPE | Dual Wheel |
| BRAND | Century |
| C DIMENSION | 9.86 IN |
| CATALOG NUMBER | D0006 |
| CONNECTION DRAWING NO | 614131-171 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 7.37 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 13.18 IN |
| MANUFACTURE MODEL NUMBER | D0006 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Resilient Rings |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2,1075(2),208-230,PSC,1PH,48 FR |
| PRODUCT SKU | D0006 |
| ROTATION | Reversible |
| RPM | 1075(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 X 4.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1075 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 208-230 V |
| WIDTH | 7.25 IN |
