| AMBIENT | 40°C |
| BEARING | Sleeve |
| BRAND | Century |
| CATALOG NUM | BR052000 |
| CE | No |
| COUNTRY OF ORIGIN | Mexico |
| CSA | Yes |
| DUTY | Continuous Air Over |
| EFFCIENCY | Standard |
| ENCLOSURE | OPEN AIR OVER |
| FL AMPS | 1.04 A |
| FRAME | C-Frame |
| FRAME MATERIAL | Rolled Steel |
| FREQUENCY | 60 HZ |
| HEIGHT | 3 IN |
| HORSE POWER | 3/4 STACK HP |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 4.5 IN |
| MANUFACTURER | Regal Beloit Epc |
| MFG MODEL NUM | BR052000 |
| MIN QUANTITY INCREMENT | 1 |
| MOTOR TYPE | Shp |
| MOUNTING | Bracket |
| NUMBER OF PHASES | 1 |
| NUMBER OF POLES | 2 |
| NUMBER OF SPEEDS | 2 |
| OVERLOAD | Automatic |
| PART ID | BR052000 |
| PRODUCT GROUP | 3050 |
| ROTATION | Counterclockwise |
| RPM | 2850(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.217 IN X 1.2 IN |
| SHAFT DIAMETER IN IN | 0.217 IN |
| SHAFT EXTENSION | 1.2 IN |
| SHAFT TYPE | Flat |
| SKU | BR052000 |
| SPEED | 2850 |
| STARTING TYPE | Across The Line |
| STATUS | Inactive |
| SUPERSEDED PART ID | K670 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UOM | Each |
| UPC NUMBER | 786674014498 |
| VOLTAGE | 120 V |
| WEIGHT STATIC | 2 LB |
| WIDTH | 2.88 IN |
