| BEARING | Sleeve |
| BLOWER TYPE | Furnace |
| BRAND | Century |
| C DIMENSION | 8.84 IN |
| CATALOG NUMBER | BL6533 |
| CONNECTION DRAWING NO | 7559A83F01 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 5.3 A |
| FRAME | 42Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 9.81 IN |
| INSULATION CLASS | A |
| LEAD TIME | 21 |
| LENGTH | 12.87 IN |
| MANUFACTURE MODEL NUMBER | BL6533 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Shp |
| MOUNTING | Flexible Arms |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/6 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/6,1050(3),115,42,OPEN,AIR-OVER,SHP |
| PRODUCT SKU | BL6533 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1050(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.6 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4.6 IN |
| SHAFT TYPE | Flat |
| SPEED | 1050 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 9.81 IN |
