| BEARING | Sleeve |
| BRAND | Century |
| C DIMENSION | 7.41 IN |
| CATALOG NUMBER | BL6409 |
| CONNECTION DRAWING NO | 261B865F01 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.1 A |
| FRAME | 42Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 5.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 17 |
| LENGTH | 8.87 IN |
| MANUFACTURE MODEL NUMBER | BL6409 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Shp |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 1 |
| ORIENTATION | Any |
| OUTPUT | 1/13 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/12,1200,115,42Y,OAO,SHP,COLEMAN |
| PRODUCT SKU | BL6409 |
| ROTATION | Counterclockwise Lead End |
| RPM | 1050(1) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 3 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 3 IN |
| SHAFT TYPE | Flat |
| SPEED | 1050 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | No |
| UNIT OF MEASURE | Each |
| VOLTAGE | 115 V |
| WIDTH | 5.81 IN |
