| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 11.09 IN |
| CATALOG NUMBER | BDH1106 |
| CONNECTION DRAWING NO | 614131-270 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | OPEN ENCLOSED |
| FL AMPS | 3.2 A |
| FRAME | 48Y |
| FREQUENCY | 60 HZ |
| HEIGHT | 6.81 IN |
| INSULATION CLASS | B |
| LEAD TIME | 18 |
| LENGTH | 15.55 IN |
| MANUFACTURE MODEL NUMBER | BDH1106 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Round Belly Band |
| NUMBER OF POLES | 6 |
| NUMBER OF SPEEDS | 3 |
| ORIENTATION | Horizontal |
| OUTPUT | 1 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1,1075/3,460,48,TEAO,PSC,1PH |
| PRODUCT SKU | BDH1106 |
| ROTATION | Reversible |
| RPM | 1100(3) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 4.5 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 4.5 IN |
| SHAFT TYPE | Flat |
| SPEED | 1100 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 460 V |
| WIDTH | 6.45 IN |
