| BEARING | Ball |
| BLOWER TYPE | Direct Drive |
| BRAND | Century |
| C DIMENSION | 12.24 IN |
| CATALOG NUMBER | BDH1054 |
| CONNECTION DRAWING NO | 614131-104 |
| DUTY | Air Over |
| EFFICIENCY | Standard |
| ENCLOSURE | SEMI ENCLOSED |
| FL AMPS | 1.4 A |
| FRAME | 48Y |
| FREQUENCY | 50/60 HZ |
| HEIGHT | 7.37 IN |
| INSULATION CLASS | B |
| LEAD TIME | 21 |
| LENGTH | 16.12 IN |
| MANUFACTURE MODEL NUMBER | BDH1054 |
| MANUFACTURER | Regal Beloit Epc |
| MOTOR TYPE | Psc |
| MOUNTING | Extended Studs |
| NOMINAL EFFICIENCY | 65.7 |
| NUMBER OF POLES | 4 |
| NUMBER OF SPEEDS | 2 |
| ORIENTATION | Horizontal |
| OUTPUT | 1/2 HP |
| OVERLOAD | Automatic |
| PRODUCT NAME | 1/2,1625(2),460,48,SEMI-ENCLOSED, PSC |
| PRODUCT SKU | BDH1054 |
| ROTATION | Reversible |
| RPM | 1625(2) |
| SERVICE FACTOR | 1 |
| SHAFT | 0.500 IN X 6.4 IN |
| SHAFT DIAMETER (IN IN.) | 0.500 IN |
| SHAFT EXTENSION | 6.4 IN |
| SHAFT TYPE | Flat |
| SPEED | 1625 |
| SUPPLIER | Regal Beloit Epc |
| TYPE OF OVERLOAD PROTECTOR | Thermally Protected |
| UL | Recognized |
| UNIT OF MEASURE | Each |
| VOLTAGE | 460 V |
| WIDTH | 7.31 IN |
